One-Cancels All (OCA) order type allows an investor to place multiple and possibly unrelated orders assigned to a group. It’s designed to allow investors to submit several orders aimed at taking advantage of the most desirable price within the group. Completion of one piece of the group causes cancellation of the remaining group orders while partial completion causes the group to rebalance.
The endpoint /iserver/account/{accounted}/orders can be used to pass order request info in an Array by setting isSingleGroup to true in each order. All orders in the same group will be assigned the same oca_group_id. After the orders are successfully placed, send the endpoint /iserver/account/order/status/{orderId} to receive the oca_group_id.
Please be sure to authenticate first in order to resolve the below URLs.
For authentication details, visit https://interactivebrokers.github.io/cpwebapi/index.html#login
POST
https://localhost:5000/v1/api/iserver/account/{accountId}/orders
Request Body:
Array () [
- acctId string
The specified Account order is placed for.
This should be one of the accounts returned by /iserver/accounts - conid string
contract identifier of the security you want to trade.
You can find the conid with /iserver/secdef/search - secType string
asset class formatted as conid:type, for example 265598:STK - cOID string
Customer Order Id. Arbitrary string that can be used to identify the order,
e.g “my-fb-order”.Value must be unique for 24h - parentId string
When placing brack orders, specify with the child order.
Must be equal to the cOID of the parent - orderType string
The type of order, example MKT (Market), LMT (Limit).
Use the endpoint /info-and-rules to determine available orderType(s) -
listingExchange string
required : false By default we use “SMART” routing.
Use the endpoint: /portal/iserver/contract/{conid}/info, to determine
valid_exchange - outsideRTH boolean
Set to true if the order can be executed outside regular trading hours - price number
For LMT this is the limit price. For STP this is the stop price -
auxPrice number
For STOP_LIMIT orders this is the Stop Price - side string
SELL or BUY - ticker string
Contract Symbol -
tif string
The time-in-force of an order, example DAY.
Use the endpoint /info-and-rules to determine tifTypes - referrer string
Order reference - quantity number
the amount or shares of the order. Usually integer, for some special cases
can be float numbers - fxQty number
double number, this is the cash quantity field used for FX conversion order - useAdaptive boolean
If true, system will use Adaptive Algo to submit the order,
ref: https://www.interactivebrokers.com/en/index.php?f=19091 - isCcyConv boolean
Set to true for a FX conversion order - allocationMethod string
Set the allocation method when placing an order using an FA account
for a group - isClose boolean
Set to true if order is closing an existing position - isSingleGroup boolean
Set to true for each order assigned to the same OCA Group.
Response:
Array () [
- id string
order_id = system generated order Id(s) for each order.
local_order_id = cOID. parent_order_id = order_Id of the parent order. - message Array of strings
if the message is a question, you must use the endpoint /iserver/reply/{replyid}
to confirm the message and submit the order.
]
Please be sure to authenticate first in order to resolve the below URLs.
For authentication details, visit https://interactivebrokers.github.io/cpwebapi/index.html#login
Example:
Submit two orders within the same /orders endpoint including isSingleGroup: true for both orders.
Request:
POST
https://localhost:5000/v1/api/iserver/account/DU***14/orders
Request Body:
{
“orders”: [
{
“acctId”: “DU***14”,
“conid”: “265598”,
“secType”: “265598:STK”,
“cOID”: “66827301”,
“orderType”: “LMT”,
“listingExchange”: “SMART”,
“outsideRTH”: true,
“price”: 145.25,
“side”: “BUY”,
“ticker”: “AAPL”,
“tif”: “DAY”,
“referrer”: “testOCA”,
“quantity”: 1,
“useAdaptive”: false,
“isClose”: false
“isSingleGroup”: true
},
{
“acctId”: “DU***14”,
“conid”: “8314”,
“secType”: “8314:STK”,
“cOID”: “66827302”,
“orderType”: “LMT”,
“listingExchange”: “SMART”,
“outsideRTH”: true,
“price”: 125.5,
“side”: “BUY”,
“ticker”: “IBML”,
“tif”: “DAY”,
“referrer”: “testOCA”,
“quantity”: 1,
“useAdaptive”: false,
“isClose”: false,
“isSingleGroup”: “true”,
}
]
}
Response:
[
{
“order_id”: “1297028126”,
“order_status”: “PreSubmitted”,
“local_order_id”: “66827302”
},
{
“order_id”: “1297028125”,
“order_status”: “Submitted”,
“parent_order_id”: “66827301”
“encrypt_message":"1”
}
] Once orders are successfully transmitted, you will return a unique order_id for each order in the Group. Send a separate /status endpoint for each order_id to identify the oca_group_id.
Request:
POST
https://localhost:5000/v1/api/iserver/account/order/status/1297028125
Response:
{
"sub_type": null,
"request_id": "193136",
"order_id": 1297028125,
"conidex": "265598",
"conid": 265598,
"symbol": "AAPL",
"side": "B",
"contract_description_1": "AAPL",
"listing_exchange": "NASDAQ.NMS",
"option_acct": "c",
"company_name": "APPLE INC",
"size": "1.0",
"total_size": "1.0",
"currency": "USD",
"account": "DU***14",
"order_type": "LIMIT",
"limit_price": "145.25",
"cum_fill": "0.0",
"order_status": "Submitted",
"order_status_description": "Order Submitted",
"tif": "DAY",
"fg_color": "#000000",
"bg_color": "#00F000",
"order_not_editable": false,
"editable_fields": "\u001e",
"cannot_cancel_order": false,
"outside_rth": true,
"deactivate_order": false,
"use_price_mgmt_algo": true,
"sec_type": "STK",
"available_chart_periods": "#R|1",
"order_description": "Buy 1 Limit 145.25 DAY",
"order_description_with_contract": "Buy 1 AAPL Limit 145.25 DAY",
"alert_active": 1,
"child_order_type": "3",
"size_and_fills": "0/1",
"oca_group_id": "oco-1297028125",
"exit_strategy_display_price": "145.25",
"exit_strategy_chart_description": "Buy 1 Limit 145.25 DAY",
"exit_strategy_tool_availability": "1",
"allowed_duplicate_opposite": true,
"order_time": "210901211533"
} Request:
POST
https://localhost:5000/v1/api/iserver/account/order/status/1297028126
Response:
{
"sub_type": null,
"request_id": "193367",
"order_id": 1297028126,
"conidex": "8314",
"conid": 8314,
"symbol": "IBM",
"side": "B",
"contract_description_1": "IBM",
"listing_exchange": "NYSE",
"option_acct": "c",
"company_name": "INTL BUSINESS MACHINES CORP",
"size": "1.0",
"total_size": "1.0",
"currency": "USD",
"account": "DU***14",
"order_type": "LIMIT",
"limit_price": "125.50",
"cum_fill": "0.0",
"order_status": "PreSubmitted",
"order_status_description": "Order Submitted",
"tif": "DAY",
"fg_color": "#FFFFFF",
"bg_color": "#0000CC",
"order_not_editable": false,
"editable_fields": "\u001e",
"cannot_cancel_order": false,
"outside_rth": false,
"deactivate_order": false,
"use_price_mgmt_algo": true,
"sec_type": "STK",
"available_chart_periods": "#R|1",
"order_description": "Buy 1 Limit 125.50 DAY",
"order_description_with_contract": "Buy 1 IBM Limit 125.50 DAY",
"alert_active": 1,
"child_order_type": "3",
"size_and_fills": "0/1",
"oca_group_id": "oco-1297028125",
"exit_strategy_display_price": "125.50",
"exit_strategy_chart_description": "Buy 1 Limit 125.50 DAY",
"exit_strategy_tool_availability": "1",
"allowed_duplicate_opposite": true,
"order_time": "210901211533"
} If you have any further questions or issues creating OCA orders, please reach out to the API Group, ref: https://www.interactivebrokers.com/en/index.php?f=47047.
Visit the IBKR API Center for Downloads, Resources, and Technical Details:
https://www.interactivebrokers.com/en/trading/ib-api.php.
